Hunting Down MS Exchange Attacks. Part 2 (CVE-2020–0688, CVE-2020–16875, CVE-2021–24085)

Logs and Useful Events

Detecting Exploitation of CVE-2020–0688

web.config file fragment
Running ysoserial utility
Cookie settings for the user authorised on the ECP service
Server response when CVE-2020–0688 is exploited
ViewState decoded
  • event_log_source:'Security' AND event_id:'4688' AND proc_parent_file_path end with:'\w3wp.exe' AND proc_file_path end with:('\cmd.exe' OR '\powershell.exe')
  • event_log_source:’IIS’ AND http_method=’GET’ AND http_status_code=’500’ AND url_path=’/ecp/default.aspx’ AND url_query contains ‘__VIEWSTATEGENERATOR’ AND hurl _query contains ‘__VIEWSTATE’
CVE-2020–0688 (IIS) exploitation event
CVE-2020–0688 (Application log) exploitation result
  • event_log_source:’Application’ AND event_id=’4’ AND (Message contains ‘__VIEWSTATE’)

Detecting Exploitation of CVE-2020–16875

  • New-RoleGroup -Name "dlp users" -Roles "Data Loss Prevention" -Members "user1" (create group dlp users with role Data Loss Prevention and add user1 to the group);
  • Update-RoleGroupMember -Members "dadmin" -identity "dlp users" (add dadmin to group dlp users).
Adding user dadmin to group dlp users (MSExchange Management log)
  • event_log_source:('PowershellAudit' OR 'MSExchange Management') AND event_id:('1' OR ’800’ OR '4104') AND ((Message contains ‘New-RoleGroup’ AND Message contains ‘Data Loss Prevention’) OR (Message contains ‘Update-RoleGroupMember’ AND Message contains ‘<Group with DLP rights>’ AND Message contains '-Members'))
  1. Authenticate under a given account to retrieve a session through OWA.
  2. Obtain the ViewState parameter by accessing the DLP policy management functionality.
  3. Add a new malicious DLP policy that contains an executable command that runs from PowerShell.
Successful exploitation of CVE-2020–16875
  • 2021-03-09 12:03:31 10.3.132.20 POST /ecp/DLPPolicy/ManagePolicyFromISV.aspx ActID=3b6c5adc-c7d0-4aeb-82ec-711c2257ece6 444 LAB\dadmin 192.168.1.20 python-requests/2.22.0 - 200 0 0 863
  • event_log_source:’IIS’ AND http_method=’POST’ AND http_code='200' AND url_path='/ecp/DLPPolicy/ManagePolicyFromISV.aspx'
New DLP policy creation event (MSExchange Management log)
  • event_log_source:('PowershellAudit' OR 'MSExchange Management') AND event_id:('1' OR ’800’ OR '4104') AND (Message contains ‘New-DlpPolicy’ AND Message contains '-TemplateData')
Process start event (Security log)
  • event_log_source:'Security' AND event_id:'4688' AND proc_parent_file_path end with:'\w3wp.exe' AND proc_file_path end with:('\cmd.exe' OR '\powershell.exe')
  1. It creates a remote PowerShell session using the PowerShell component of the Exchange server. The account attempting the connection must have the Data Loss Prevention role.
Code snippet for creating a remote PowerShell session
Running New-DlpPolicy within a remote PowerShell session
  • 2021-03-09 13:47:04 10.3.132.20 POST /powershell serializationLevel=Full;ExchClientVer=15.1.1591.10;clientApplication=ManagementShell;TargetServer=;PSVersion=5.1.14393.693&sessionID=Version_15.1_(Build_1590.10)=rJqNiZqNgZqHnJeekZia0bO+vdGzsLy+s4HOxsvNz8nNycvIgc3Pzc7Sz8zSz8arzszFysvFz8s= 444 lab\dadmin 192.168.1.20 Microsoft+WinRM+Client - 500 687 0 180002
  • event_log_source:’IIS’ AND http_method=’POST’ AND url_path='/powershell' AND (Message contains ‘serializationLevel=Full AND Message contains 'clientApplication=ManagementShell') AND user_agent='Microsoft+WinRM+Client'
whoami process start event

Detecting Exploitation of CVE-2021–24085

  1. Compromise an arbitrary domain account that has a mailbox.
  2. Use the ECP interface to export the certificate.
  3. Using the certificate obtained, generate a CSRF token, aka the msExchEcpCanary parameter.
  4. Get the Exchange administrator to go to the attacker’s malicious page, which will send a request to the Exchange server with the preset token value on behalf of the administrator.
Successful export of the certificate
  • 2021-03-09 15:52:55 10.3.132.20 POST /ecp/DDI/DDIService.svc/SetObject schema=ExportCertificate&msExchEcpCanary=yylkJJJocUWa3HVCEcQli7B3FcF--tgI2nbpJpHLcFZ60E9sZ2gmDpi_sFqf3jl9YcG9qcRMzek.&ActID=cf99b7d2-4eac-4435-a041-f0adaa44ed94 444 LAB\dadmin 192.168.1.20 python-requests/2.22.0 - 200 0 0 500
  • 2021-03-09 15:52:55 10.3.132.20 GET /ecp/poc.png - 444 LAB\EXCHANGE$ 192.168.1.20 python-requests/2.22.0 - 200 0 0 7
  • event_log_source:’IIS’ AND http_method=’POST’ AND http_code='200' AND url_path='/ecp/DDI/DDIService.svc/SetObject' AND (Message contains 'schema=ExportCertificate')
Generating the msExchEcpCanary parameter
  • Add via the URL where the add-in is located.
  • Download from the Office Store.
  • Download a new add-in from file.
Adding a new add-in via the ECP interface
Adding an add-in using JavaScript
  • event_log_source:’IIS’ AND http_method=’POST’ AND http_code='200' AND url_path='/ecp/Handlers/UploadHandler.ashx'

Conclusion

--

--

--

BI.ZONE: an expert in digital risks management. We help organizations around the world to develop their businesses safely in the digital age
